nxV200 VFET-MOSFET Amplifier Module

$179.00AUD each...

They are selling fast!!!

OEM & DIY Enquiries Welcome!!!

For Quantity Pricing please

Email aussieamplifiers@bigpond.com

The all new nxV200 VFET-MOSFET Audio Amplifier Module is a very high performance, high end audio amplifier module.

The sound quality from this amplifier module is absolutely stunning!!!

Utilising the latest SMD low noise, high linearity Toshiba and Zetex transistors

And very rugged high performance Toshiba VFET-MOSFET output stage.

The Topology is based around a highly refined complementary differential input stage, with a super high gain, high linearity MOSFET cascoded VAS. With a complementary Toshiba VFET output stage.

The nxV200 has a flat distortion curve 0.006% from 5hz to 20khz and a frequency response of 5hz to 300khz -3dB and a very low noise amplification of -120dB and is able to drive on a continuous sine wave basis into 4 ohm loads and up.

But the nxV200 is not all specification's the sound quality is very detailed and has a wonderful deep sound stage and does not have the dry flat sound quality often reported by user's of Class D audio amplifiers.

The nxV200 is designed for use in...

  • Audiophile Amplifiers
  • Home Theatre Systems
  • Recording Studios
  • Public Address Systems
  • Powered Loudspeakers

Module below showing the high precision LED voltage sources.

  • Measuring only 50mm(2") x 50mm(2")
  • Ultra heavy duty FR4, Gold Emmersion, 3 Ounce copper PCB
  • Using High performance complementary Toshiba Power MOSFETs
  • 110 Watts RMS min continuous sine-wave rated into 8 Ohms
  • 180 Watts RMS min continuous sine-wave rated into 4 Ohms
  • -120dB SNR 0.006% THD - 5hz to 20khz
  • Frequency Response - 5Hz-500Khz -3dB
  • Power bandwidth - 5hz-100khz
  • Power Supply Rejection greater than -105dB
  • Damping Factor - 400
  • Unconditionally Stable into any load from 4 to 16 Ohms
  • The nxv200 is 2 Ohm stable.
